Technical Specifications
Datasheet PDF
| Insertion Loss | < 1 db to 5 GHz; -2 dB at 10 GHz |
|---|---|
| Return Loss | 25 dB at 10 GHz |
| Rise Time | 20 ps |
| Bandwidth | 16 kHz to 20 GHz |
| ROHS compliance | Yes, assembled with lead-free solder |
| Warranty | 1 year, repair or replacement |
The Hyperlabs online store is closed for the holidays, and we will return on January 2, 2025.
HL9440
HL9440 Broadband DC Bias Tee (Individual Unmatched)
DISCONTINUED
EFFECTIVE MAY 21, 2020, THIS PRODUCT IS NO LONGER AVAILABLE FOR PURCHASE. EXISTING CUSTOMERS SHOULD CONTACT HYPERLABS FOR SUPPORT.
The HL9440 is a broadband DC bias tee that allows for the insertion of a DC bias current into a circuit with minimal perturbation of the impedance of a 50 ohm transmission line.
Data and Documentation
Ordering and Shipping
This product is built to order. Please contact us for lead time information.
